ScorTail 30 Oil Recovery Skimmer

Share

FREE-FLOATING or ADVANCING OIL RECOVERY SKIMMER SYSTEM OLEOPHILIC BELT BRUSH x3 & INTEGRATED PUMP RECOVERY SYSTEM

ScorTail 30 Oil Recovery Skimmer

https://www.oilspillresponse.gr/wp-content/uploads/2024/11/05_Scortail-30_In-Water-with-Power-Pack-15-kW-min-scaled.jpg
https://www.oilspillresponse.gr/wp-content/uploads/2024/11/DSC_1924_MIN.jpg
https://www.oilspillresponse.gr/wp-content/uploads/2024/11/Gelasakis-Suda-Bay-7_site-scaled-e1736692797808.jpg
https://www.oilspillresponse.gr/wp-content/uploads/2024/11/IMG_6965_MIN.jpg

New Naval’s ScorTail 30 Belt Brush Oil Skimmer is a portable belt and brush oil recovery system capable of recovering light to heavy viscosity oils. The skimmer incorporates proven oleophilic brush technology and is capable ofachieving high recovery capacities with optimum efficiency. The skimmer can be used either independently with its own floats or can be mounted easily on a vessel, either as a bow collector or a side collector converting a workboat into an advancing system. Equipped with a transfer pump, the whole system is easily deployed and highly efficient in processing large volume spills.


 Portable belt and brush oil recovery system capable of recovering light to heavy viscosity oils.


Key Features

  • Advancing or temporary system
  • 98% oil recovery rate, <2% water content
  • Light to heavy oil recovery
  • High recovery rate system
  • Proven oleophilic recovery system utilizing 3 brush rows

Areas of Application

  • Nearshore & Offshore
  • Inland Waters
  • Ports & Harbors

Technical Specifications

Recovery Capacity30 m3/h
Dimensions (LxWxH)2000 mm x 1550 mm x 1405 mm
Weight229 kg
Skimmer FrameMarine Grade Aluminium
Recovery MeansOleophilic Belt Conveyor Brush
Number of Brush Rows3
Discharge PumpOn-board or Remote
Discharge Connection2” Camlock
Hydraulic Flow Rate12 lpm
Hydraulic Pressure110 bar
Hydraulic Connections3/8” – 1/2”
