ScorPack 42 kW

New Naval’s ScorPack 42 kW (Hydraulic Power Unit) is a compact hydraulic power pack intended to power equipment with medium power requirements. The robust design of the power pack makes it ideal for operation in harsh environments. The power pack is portable, wheels allow it to be transported removing the need for cranes or forklifts. The system can easily operate a hydraulic-driven Scorpion Boom Storage Reel or oil skimmer, such as the ScorLip 205 Weir oil recovery skimmer.

TECHNICAL DATA

Dimensions (LxWxH)	1920 mm x 1000 mm x 1300 mm
Frame Material	Epoxy coated mild steel
Weight Dry/Wet	620 kg / 840 kg
Engine	Deutz or similar (Yanmar, Lombardini, Baudouin)
Power Output	42 kW
Hydraulic Flow Rate	128 lpm
Hydraulic Pressure	280 bar
Hydraulic Output	1/4” – 1”
Engine Start	Electric
Fuel	Diesel
