Lobe Pump

The Vogelsang lobe pump is an ideal rotary transfer pump designed for heavy-duty, versatile applications including oil spill response operations, ship to ship transfers (lightering), tank cleaning procedures and other tasks where liquid transfers, especially high-volume or viscous liquids i.e. crude oils, take place. The pump comes in a protective metal casing equipped with lifting eyes and a hydraulic platform to quickly and easily connect the system to a hydraulic power source

Heavy-Duty Power, Built for Precision

Key Features

Transfers a range of viscosities
Versatile applications
Pairs with a variety of oil spill response equipment
Vogelsang VX100-64Q has continuously provided world-renowned performance

Pump Application

Liquid Transfer
Dewatering
Lightering
Oil Spill Response Operations
High-capacity Operations
Viscous Oil Transfer Operations

Technical Specifications

Model	Vogelsang VX100-64Q	Vogelsang VX100-128Q	Vogelsang VX136-105Q
Max. Capacity	20 m³/h	50 m³/h	90 m³/h
Displacement	42 l/100rev	84 l/100rev	190 l/100rev
Max. Pressure	9 bar	4 bar	10 bar
Dimensions (LxWxH)	900 mm x 660 mm x 700 mm	900 mm x 660 mm x 700 mm	1030 mm x 710 mm x 850 mm
Weight Dry (Approx.)	85 kg	93 kg	167kg
Solids Size (max.)	42 mm	22 mm	40 mm
Max. Pump Speed	1000 rpm	1000 rpm	800 rpm
Inlet/Outlet Port	3’’ Camlock	3’’ Camlock	3’’ Camlock
Required Power	10 kW	10 kW	16 kW
